| 產品快照 | ||||||
| 功率等級 | 8-40 kVA | |||||
| 額定電壓 | 380-400-415V | |||||
| 頻率 | 50/60 Hz | |||||
| 配置 | Tower | |||||
| 產品系列 | Powerware | |||||
| 獨立式3相輸入UPS | ||||||
| 零件號 | 說明 | 額定功率 | 運行時間(因數0.7) | 尺寸（HXWXD） | 重量 | |
| 1023411 | 9355-8-N-15-32x9Ah | 8 kVA / 7.2 kW | 15 MIN | 817x305x702 MM | 165 KG | |
| 1023412 | 9355-8-N-33-64x9Ah | 8 kVA / 7.2 kW | 33 MIN | 1214x305x702 MM | 280 KG | |
| 1023413 | 9355-10-N-10-32x9Ah | 10 kVA / 9 kW | 10 MIN | 817x305x702 MM | 165 KG | |
| 1023414 | 9355-10-N-25-64x9Ah | 10 kVA / 9 kW | 25 MIN | 1214x305x702 MM | 280 KG | |
| 1023415 | 9355-12-N-8-32x9Ah | 12 kVA / 10.5 kW | 8 MIN | 817x305x702 MM | 165 KG | |
| 1023416 | 9355-12-N-20-64x9Ah | 12 kVA / 10.5 kW | 20 MIN | 1214x305x702 MM | 280 KG | |
| 1023417 | 9355-15-N-5-32x9Ah | 15 kVA / 13.5 kW | 5 MIN | 817x305x702 MM | 165 KG | |
| 1023418 | 9355-15-N-15-64x9Ah | 15 kVA / 13.5 kW | 15 MIN | 1214x305x702 MM | 280 KG | |
| 1025061 | 9355-20-N-5-1x9Ah-MBS | 20 kVA / 18 kW | 5 MIN | 1684x494x762 MM | 300 KG | |
| 1025062 | 9355-20-N-13-2x9Ah-MBS | 20 kVA / 18 kW | 13 MIN | 1684x494x762 MM | 400 KG | |
| 1025063 | 9355-20-N-22-3x9Ah-MBS | 20 kVA / 18 kW | 22 MIN | 1684x494x762 MM | 500 KG | |
| 1025064 | 9355-20-N-31-4x9Ah-MBS | 20 kVA / 18 kW | 31 MIN | 1684x494x762 MM | 600 KG | |
| 1025065 | 9355-30-N-7-2x9Ah-MBS | 30 kVA / 27 kW | 7 MIN | 1684x494x762 MM | 400 KG | |
| 1025066 | 9355-30-N-13-3x9Ah-MBS | 30 kVA / 27 kW | 12 MIN | 1684x494x762 MM | 500 KG | |
| 1025067 | 9355-30-N-20-4x9Ah-MBS | 30 kVA / 27 kW | 20 MIN | 1684x494x762 MM | 600 KG | |
| 1025795 | 9355-40-N-8-3x9Ah-MBS | 40 kVA / 36 kW | 8 MIN | 1684x494x762 MM | 517 KG | |
| 1025796 | 9355-40-N-12-4x9Ah-MBS | 40 kVA / 36 kW | 12 MIN | 1684x494x762 MM | 617 KG | |
| 外置電池柜8 - 15 KVA | ||||||
| 零件號 | 說明 | 額定功率 | 尺寸（HXWXD） | 重量 | ||
| 1022561 | 9355-BAT5-64X7AH | 2X32X7 AH | 817x305x699 MM | 195 KG | ||
| 1022562 | 9355-BAT5-96X7AH | 2X32X7 AH | 1214x305x699 MM | 310 KG | ||
| 外置電池柜20 - 40 KVA | ||||||
| 零件號 | 說明 | 額定功率 | 尺寸（HXWXD） | 重量 | ||
| 1025169 | 9355-BAT-1X24AH (30 KVA) | 1X36X24 AH | 1684x494x758 MM | 510 KG | ||
| 1025170 | 9355-BAT-2X24AH (30 KVA) | 2X36X24 AH | 1684x494x758 MM | 870 KG | ||
